| Test Parameter | Method |
|---|---|
| Ester & Linolenic acid methyl ester content | DIN EN 14103 |
| Density at 15 °C | DIN EN ISO 12185 |
| Kinematic viscosity at 40 °C | DIN EN ISO 3104 |
| Flash point | DIN EN ISO 2719 DIN EN ISO 3679 |
| Cetane number (ICN) | DIN EN 17155 |
| Copper strip corrosion (3 h at 50 °C) | DIN EN ISO 2160 |
| Oxidation stability at 110 °C | DIN EN 14112 DIN EN 15751 |
| Acid value | DIN EN 14104 |
| Iodine value | DIN EN 16300 |
| Polyunsaturated fatty acid methyl esters content with ≥ 4 double bonds | DIN EN 15779 |
| Methanol content | DIN EN 14110 |
| Glycerides, total & free Glycerol | DIN EN 14105 |
| Water content | DIN EN ISO 12937 |
| Total contamination | DIN EN 12662 |
| Ash content (sulfated ash) | DIN ISO 3987 |
| Sulfur content | DIN EN ISO 20884 DIN EN ISO 20846 |
| Alkali metals content (Na+K) | DIN EN 14538 |
| Alkaline earth metals content (Ca+Mg) | DIN EN 14538 |
| Phosphorus content | DIN EN 14107 |
| CFPP | DIN EN 116 |
| Cloud point | DIN EN 23015 |
We analyse our biodiesel ourselves, but we need reference materials for quality assurance. What does ASG offer in this regard?
ASG distributes both its own products and the QC materials provided by AGQM (https://asg-analytik.de/en/products/qc-materials-standards/).
A supplier offers us an attractive raw material for biodiesel production, can ASG help us to check its suitability?
Yes, we can determine the key figures of the raw material as well as carry out conversion or esterification and thus also analyze the potential end product.
In our plant, distillation is also carried out after conversion and esterification, can this step also be reconstructed at ASG?
Our technical center has a wide range of systems. There, a corresponding distillation step can also be carried out on the basis of your process parameters and its success can be immediately proven in the analysis laboratory.
On the ASG website there are 2 biodiesel specifications, (DIN) EN 14214 and ASTM D6751 - are there any differences?
Yes, these specifications have been designed for different markets, on the one hand for Europe with EN 14214 and on the other hand for ASTM D6751, which is widespread in the USA and Asia. The two standards differ in terms of test parameters and test methods as well as limit values and are therefore not comparable 1:1.
I need analyses of my raw materials and auxiliary materials as well as the intermediates and by-products, can ASG also help me in these areas?
Our range of services covers all areas of biodiesel production, including the testing of products such as vegetable oils and fats, fatty acids, crude or pharmaceutical glycerol, methanol, catalyst (NaOH, Na-methylate, toluenesulfonic acid) see e.g. https://asg-analytik.de/en/analytics/crude-glycerol/
We would like to use a new additive package in our tank farm. How can its effectiveness be proven specifically for our product?
ASG can produce mixtures in different concentrations with additives provided by the customer as well as with products from our own large pool and test them for CFPP or oxidation stability, for example.
I'm looking for a suitable product to add to our final B100 in terms of both stability and cold resistance – what do I have to pay attention to?
On behalf of the Arbeitsgemeinschaft Qualitätsmanagement Biodiesel AGQM, ASG has been carrying out the “no-harm” tests for additives for many years, see https://www.agqm-biodiesel.de/downloads/no-harm. All products mentioned there have passed defined test criteria and are therefore considered recommendable.
Our biodiesel complies with DIN EN 14214 (ASTM D6751) in all respects, but our customers still report problems. Can ASG also help us in such cases?
Thanks to our more than 30 years of experience in this field, we have already been able to provide useful answers to many customers with complex tasks. To this end, we are not only investigating biodiesel patterns, but also, for example, tank sediments or fuel pump filters.
A potential buyer wants key figures of our product that go beyond the scope of EN 14214 (ASTM D6751). Is this common and what do I have to do now?
In the national and international trade in biodiesel, delivery specifications (e.g. ARGUS) have now been established that include other parameters. ASG routinely offers all possible analyses, such as pour point or fatty acid samples.
Is it possible to determine which raw material was used to make a biodiesel?
Both B100 and blends such as B7 can be used to determine the fatty acid profile of the biodiesel they contain. In the case of pure vegetable oils such as rapeseed, soybean or palm oil, this can be assigned quite clearly, and animal components are also easily detectable. In the case of blends and biodiesel from used edible fats (“UCOME”), the significance is put into perspective accordingly.
Are biodiesel and HVO the same?
No, biodiesel (fatty acid methyl ester, FAME) is produced from biogenic oils, fats or fatty acids through a transesterification or esterification process. HVO is produced by the hydrogenation of vegetable oils, and the hydrocarbons obtained in the process are very similar in their properties to those of a fossil diesel fuel.
The analysis using GCxGC (ASG 2253 or ASG 2502) provides additional methods. You can find more information in the Special Analytics section or upon request.
DIN EN 14214
Download your analysis order form. After filling it out, please send it to us along with your product sample. Please see our Sample Shipping Guidelines.
We have been accredited for the
analysis of fuels since 1998.
The flexible accreditation allows the application of accredited test procedures with different dates of publication. Therefore, it may happen that an (outdated) version listed in the official annex to the accreditation certificate D-PL-11334-01-00 is no longer used in the ASG laboratory. A list that reflects the current status of the flexible accreditation is available by pressing the button “method list”.
Do you require specialized analytical methods for other substances or mixtures? Then you'll find what you need in our special analytics services.
